TFT LCDSAMSUNG 7.0 inch TFT LCD Screen LMS700KF25
Mouse over to zoom in
- Product 200/374
-
Brand: SAMSUNG
Model: LMS700KF25
Diagonal Size: 7.0 inch
Type: a-Si TFT-LCD, LCM
Pixel Format: 800(RGB)*480 WVGA
Configuration: RGB Vertical Stripe
Surface:
Brightness: 350 cd/m² (Typ.)
Contrast Ratio: 700:1 (Typ.) (TM)
Response Time: 16 (Typ.)(Tr+Td) ms
Viewing Angle: 70/70/70/70 (Typ.)(CR≥10)
Operating Mode: TN, Normally White, TMR
Support Color: 16.2M 50% (CIE1931)
Lamp Type: 8S3P WLED
Frame Rate: 60Hz
Touch Panel: No
Interface Type: 40 pins CMOS (1 ch, 8-bit) , FPC
Power Supply: 3.3V (Typ.)
Operating Temperature: -20 ~ 60°C
Storage Temperature: -30 ~ 70 °C
Application: MP4 PMP Panel, MID UMPC Panel
