TFT LCDHannStar 7 inch TFT LCD Panel HSD070PFW1-A00
Mouse over to zoom in
- Product 368/374
-
Panel Brand: HannStar
Panel Model: HSD070PFW1-A00
Panel Type: a-Si TFT-LCD, Panel
Panel Size: 7.0 inch
Resolution: 1024(RGB)*600, WSVGA
Display Mode: TN, Normally White, Transmissive
Surface: Glare (Haze 0%), Hard coating (3H), Reflection 1.5% (Max.)
Brightness: 450 cd/m2 (Typ.)
Contrast Ratio: 800:1 (Typ.)
Display Color: 16.7M (6-bit + Hi-FRC)
Response Rime: 4/12 (Typ.) (Tr/Td)
Viewing Angle: 80/80/80/70 (Typ.) (CR≥10) (L/R/U/D)
Frequency: 60Hz
Lamp Type: 3S7P WLED
Signal Interface: LVDS (1 ch, 8-bit)
Input Voltage: 3.2/4.2V (Min.Max.)
RoHS
Application: All Netbook PC Panel
