TFT LCDChiHsin 8.0 inch TFT LCD Panel LW800AT9001 800*480
Mouse over to zoom in
- Product 79/121
-
Brand: ChiHsin
Model: LW800AT9001
Diagonal Size: 8.0 inch
Type: a-Si TFT-LCD, LCM
Pixel Format: 800(RGB)×480 WVGA
Configuration: RGB Vertical Stripe
Surface:
Brightness: 300 cd/m² (Typ.)
Contrast Ratio: 400:1 (Typ.) (TM)
Response Time: 5/15 (Typ.)(Tr/Td) ms
Viewing Angle: 65/65/50/65 (Typ.)(CR≥10)
Operating Mode:
Support Color: 262K
Lamp Type: 3S9P WLED
Frame Rate:
Touch Panel: Without
Interface Type: Parallel RGB (1 ch, 6-bit) , 60 pins, FPC
Power Supply: 3.3/12/18/-7V (Typ.) (VCC/AVDD/VGH/VGL)
Operating Temperature: -20 ~ 70°C
Storage Temperature: -30 ~ 80 °C
Application: All Digital Photo Frame Panel, All Portable DVD Player Panel
